Description
Specifications
Backwash Flow Rate | 74 |
---|---|
Brand | Hayward |
Cartridge | No |
Channel | Open Line |
Design Flow Rate | 74 |
Drain Port Size | 1.5 |
Effective Filtration Area | 3.7 SQFT |
Filter Type | Sand |
Footprint | 27-1/2 x 27-1/2" |
GTIN | 610377387767 |
Labor Warranty | None |
Master Carton Qty | 1 |
Maximum Working Pressure | 50 PSI |
Number of Filter Elements | N/A |
Pallet Qty | 8 |
Parts Warranty | 3-year |
Pool Type | In Ground |
Pressure Gauge | Yes |
Product Dimensions | 43 " x 27.5 " x 27.5 " |
Product Height | 43 in |
Product Length | 27.5 in |
Product Weight | 68 lb |
Product Width | 27.5 in |
Public Design Flow Rate | 74 |
Residential Design Flow Rate | 74 |
Sand Capacity | 500 lbs |
Series Filters | ProSeries |
Shipping Dimensions | 44.9 " x 27.8 " x 27.8 " |
Shipping Height | 44.9 in |
Shipping Length | 27.8 in |
Shipping Weight | 64 lb |
Shipping Width | 27.8 in |
Side Clearance - Filters | 18 in |
Tank Type | Polymeric Resin |
Turnover 10 Hours | 44400 GPM |
Turnover 8 Hours | 35520 GPM |
Valve Included | 1 1/2" VariFlo |
Vertical Clearance Filters | 18 in |
